Chapter 3

Part names and functions

(9) Sheath reagent aspiration connector
CyFlow SHEATH is aspirated through this connector.
(10) Waste fluid outlet connector
Discharges waste fluid. Connect to a waste container or a waste fluid tank at the facility using the provided drain
tubing.

3.2

IPU (Information Processing Unit)

IPU
The operation of the IPU is based on Microsoft Windows. For information on how to use Microsoft Windows, see
the manual included with the operating system.

Caution
The IPU is a PC that is designed only for use with the instrument. It cannot be used as a general-purpose PC.

(1)

(2)

(4)

(3)

(1)
(2)
(3)
(4)

Monitor
Keyboard
Mouse
Main unit

Information
The above diagram is for reference only. Refer to the computer's manual for the location of connection ports and
other information.
For details, please contact your authorized local Sysmex representative.
